| JTL-Product | Package | Product status | Technology | Polarity | ESD | ID (A) | PD (W) | V(BR)DSS (V) | VGS (V) | VTH(V) | RDS(on) ()@VGS=10V | RDS(on) ()@VGS=4.5V | RDS(on) ()@VGS=2.5V | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Typ | Max | Typ | Max | Typ | Max | |||||||||||
| JTL2302B | SOT-23 | Production | Trench | N | N | 2.5 | 1 | 20 | ±12 | -0.35-0.7-1.1 | 45 | 55 | 62 | 85 | ||
| JTL2302 | SOT-23 | Production | Trench | N | N | 3 | 1 | 20 | ±12 | 0.5-0.95-1.5 | 38 | 60 | 49 | 115 | ||
| JTL3400 | SOT-23 | Production | Trench | N | N | 5.8 | 1.4 | 30 | ±12 | 0.5-0.87-1.3 | 22 | 26 | 25 | 30 | 37 | 42 |
| SOT-23 | Eng | Trench | N | N | 5.8 | 1.4 | 30 | ±12 | 0.7-1-1.4 | 21 | 30 | 25 | 35 | 39 | 55 | |
